ASUS PRIME B760M-A GAMING INTEL LGA 1700 DDR5 Motherboard
Price: 20,500৳
Stock: In stock
Product Code: #2075
Brand: Asus
Key Features:
Intel LGA 1700 socket for 14th, 13th & 12th Gen Intel Processors
Intel B760 Chipset
4 x DIMM, Max. 128GB, DDR5 8000+(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 Non-ECC, Un-buffered Memory
PCIe 4.0 support
Realtek 2.5Gb Ethernet
1 x DisplayPort, 2 x HDMI ports
Payment Options
Selected: Cash
Specification
| Audio | |
| Audio | Realtek 7.1 Surround Sound High Definition Audio CODEC |
| Audio Features | Premium audio capacitors, Audio Shielding, Dedicated audio PCB layers |
| Back Panel I/O Ports | |
| Back Panel I/O Ports | USB ports, DisplayPort, HDMI, Ethernet, Audio jacks |
| Bios | |
| Bios | 128 Mb Flash ROM, UEFI AMI BIOS |
| Memory | |
| Channel Supported | Dual Channel |
| Maximum Memory | 128 GB |
| Optimem Ii | Yes |
| Slots | 4 x DIMM |
| Supported Memory | 8000+(OC)/7800(OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600(OC)/5400(OC)/5200/5000/4800 Non-ECC, Un-buffered Memory |
| Type | DDR5 |
| Chipset | |
| Chipset | Intel B760 |
| Ethernet | |
| Ethernet | Realtek 2.5 Gb Ethernet |
| Form Factor | |
| Form Factor | mATX |
| Usb | |
| Front Usb | 7 ports |
| Front Usb 3.2 Gen 1 Type-C® | Yes |
| Rear Usb | 6 ports |
| Graphics | |
| Graphics | 1 x DisplayPort, 2 x HDMI ports |
| Multi-Gpu Support | No |
| Internal I/O Ports | |
| Internal I/O Ports | Fan headers, Aura RGB headers, Addressable Gen 2 headers, USB headers, SATA connectors, etc. |
| Storage | |
| M.2 Slot | 1 x M.2 2280 (PCIe 4.0 x4 mode), 1 x M.2 2280 (PCIe 4.0 x4 mode) |
| Sata | 4 x SATA 6 Gb/s |
| Total Supports | 2 x M.2 slots and 4 x SATA 6 Gb/s ports |
| Expansion Slots | |
| Pci | 1 x PCIe 4.0 x16 slot, 2 x PCIe 4.0 x1 slots |
| Pcie 4.0 Slot Support | Yes |
| Special Features | |
| Special Features | ASUS 5 X Protection III, ASUS OptiMem, ASUS EPU, AI Suite 3, Ai Charger, PC Cleaner, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design, M.2 Onboard |
| Processor | |
| Supported Cpu | Intel Socket LGA1700 for 14 th Gen, 13 th Gen & 12 th Gen Intel Core, Pentium Gold and Celeron Processors |
| Supports Intel Turbo Boost Technology 2.0 And Intel Turbo Boost Max Technology 3.0 | Yes |
| Operating System Support | |
| Supported Operating System | Windows 11 / 10 |
| Warranty Information | |
| Warranty | 3 Years |
Description
The ASUS PRIME B760M-A is a microATX motherboard for Intel's LGA 1700 socket that offers a flexible foundation for developing powerful and feature-rich computer systems. This motherboard, designed for 14th, 13th, and 12th Gen Intel processors, assures compatibility with a wide selection of CPUs, giving consumers freedom in selecting their chosen processor. The ASUS PRIME B760M-A is a feature-rich mATX motherboard with powerful performance, extensive connections, effective cooling, and configurable aesthetics, making it a great choice for anyone wishing to construct a high-quality and visually pleasing system.
Best ASUS PRIME B760M-A GAMING INTEL LGA 1700 DDR5 Motherboard price in BD
ASUS PRIME B760M-A GAMING INTEL LGA 1700 DDR5 Motherboard price in Bangladesh starts from ৳20,500. Price may vary based on configuration and availability. Order from the Primes Computers website or visit our showrooms.
