Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard
Price: To be announced
Stock: Out of stock
Product Code: #120
Brand: Gigabyte
Key Features:
Model: Gigabyte A520M DS3H Ultra Durable
Supports AMD Ryzen 5000/4000G/3rd Gen CPUs
Ultra-Fast NVMe M.2
RGB FUSION 2.0 Supported
5+3 Phases Digital VRM
Micro ATX Form Factor
Payment Options
Selected: Cash
Specification
| Special Features | |
| @Bios | Supported |
| App Center | Supported |
| Q-Flash Plus | Supported |
| Rgb Fusion 2.0 | Supported |
| Xpress Install | Supported |
| Audio | |
| Channels | 2/4/5.1/7.1-channel High Definition Audio |
| Codec | Realtek ALC887 |
| Basic Information | |
| Chipset | AMD A520 |
| Form Factor | Micro ATX (24.4 cm x 24.4 cm) |
| Supported Cpu | AMD Ryzen 5000/4000 G Series & AMD Ryzen 3 rd Generation Processors |
| Graphics | |
| Displayport | 1 x DisplayPort (5120x2880@60 Hz) |
| Dvi-D | 1 x DVI-D (1920x1200@60 Hz) |
| Hdmi | 1 x HDMI (4096x2160@60 Hz) |
| Max Displays | 3 |
| Max Shared Memory | 16 GB |
| Internal I/O Ports | |
| Fan Headers | 1 x CPU fan, 2 x system fan |
| Led Headers | 1 x Addressable LED, 1 x RGB LED |
| Others | Serial port header, Q-Flash Plus button, Clear CMOS jumper |
| Power | 1 x 24-pin ATX, 1 x 8-pin ATX 12 V |
| Usb Headers | 1 x USB 3.2 Gen 1, 1 x USB 2.0 |
| Tpm (Trusted Platform Module) | |
| Header | 1 x TPM header (2x6 pin, GC-TPM2.0_S module) |
| Connectivity | |
| Lan | Realtek GbE LAN (1000 Mbit) |
| Usb Ports | 4 x USB 3.2 Gen 1 (rear), 2 x USB 3.2 Gen 1 (internal), 4 x USB 2.0 (2 rear, 2 internal) |
| Storage | |
| M.2 Slot | 1 x M.2 (2242/2260/2280 SATA and PCIe 3.0 x4/x2) |
| Raid Support | RAID 0, 1, 10 |
| Sata Ports | 4 x SATA 6 Gb/s |
| Memory | |
| Maximum Memory | 128 GB |
| Slots | 4 x DIMM |
| Supported Memory | Up to DDR4 4733(O.C.) |
| Type | DDR4, Dual Channel |
| Expansion Slots | |
| Pcie X1 | 2 x PCIe 3.0 x1 |
| Pcie X16 | 1 x PCIe 3.0 x16 |
| Warranty Information | |
| Warranty | 3 Years |
Description
The Gigabyte A520M DS3H is a durable and performance-focused Micro-ATX motherboard designed for AMD Ryzen 5000, 4000G, and 3rd Generation processors. It features a 5+3 Phases Pure Digital VRM solution for stable power delivery, dual-channel DDR4 memory support up to 128GB, and a high-speed NVMe PCIe 3.0 x4 M.2 slot. The board supports RGB Fusion 2.0 for customizable lighting and provides multiple display outputs including HDMI, DisplayPort, and DVI-D, making it an excellent choice for budget gaming or productivity builds.
Best Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard price in BD
Gigabyte A520M DS3H Micro-ATX AMD AM4 Motherboard price in Bangladesh — please call/message for the latest price. Price may vary based on configuration and availability. Order from the Primes Computers website or visit our showrooms.
