MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard
Price: 20,700৳
Stock: In stock
Product Code: #2062
Brand: Msi
Key Features:
Model: PRO B650-S WIFI
Supported CPU: Ryzen 9000/ 8000/ 7000 Series Processors for Socket AM5
Supported RAM: 4x DDR5, up to 7200+(OC) MHz
Graphics Output: 1x HDMI, 1x Display Port
Features: 2.5G LAN with Wi-Fi 6E Solution
Payment Options
Selected: Cash
Specification
| Basic Information | |
| Audio | Realtek ALC897 Codec, 7.1-Channel High Definition Audio |
| Chipset | AMD B650 |
| Form Factor | ATX, 243.84mmx304.8 mm |
| Supported Cpu | Supports AMD Ryzen 9000/ 8000 & 7000 Series Desktop Processors, Socket AM5 |
| Connector & Ports | |
| Audio | Audio Connectors |
| Display Port(S) | 1 x DisplayPort |
| Hdmi | 1 x HDMI |
| Internal I/O Ports | INTERNAL IO: 1 x Power Connector(ATX_PWR), 2 x Power Connector(CPU_PWR), 1 x CPU Fan, 1 x Pump Fan, 4 x System Fan, 2 x Front Panel (JFP), 1 x Chassis Intrusion (JCI), 1 x Front Audio (JAUD), 1 x Com Port (JCOM), 1 x Tuning Controller connector(JDASH), 2 x Addressable V2 RGB LED connector (JARGB_V2), 2 x RGB LED connector(JRGB), 1 x TPM pin header(Support TPM 2.0), 4 x USB 2.0 ports, 2 x USB 3.2 Gen1 Type A ports, 1 x USB 3.2 Gen2 Type C ports; BACK PANEL PORTS: DisplayPort, 2.5 G LAN, USB 3.2 Gen 2 10 Gbps (Type-A), USB 3.2 Gen 1 5 Gbps (Type-A), Wi-Fi / Bluetooth, Audio connectors, Flash BIOS Button, HDMI, USB 3.2 Gen 2 10 Gbps (Type-A), USB 3.2 Gen 2x2 20 Gbps (Type-C) |
| Lan Port(S) | Realtek 8125 BG 2.5 G LAN |
| Raid | Supports RAID 0 and RAID 1 for SATA storage devices; Supports RAID 0 and RAID 1 for M.2 NVMe storage devices |
| Supported Storage | 2 x M.2; M.2_1 Source (From CPU) supports up to PCIe 4.0 x4, supports 22110/2280 devices; M.2_2 Source (From CPU) supports up to PCIe 4.0 x4, supports 2280/2260 devices; 4 x SATA 6 G |
| Tpm (Trusted Platform Module) | 1 x TPM pin header(Support TPM 2.0) |
| Usb(S) | 4 x USB 2.0 (Front), 4 x USB 3.2 Gen1 Type A (Rear), 2 x USB 3.2 Gen1 Type A (Front), 3 x USB 3.2 Gen2 Type A (Rear), 1 x USB 3.2 Gen2 Type C (Front), 1 x USB 3.2 Gen2x2 Type C (Rear) |
| Wireless Communication Module | AMD Wi-Fi 6 E; The Wireless module is pre-installed in the M.2 (Key-E) slot; Supports MU-MIMO TX/RX; Supports 20 MHz, 40 MHz, 80 MHz bandwidth in 2.4 GHz/ 5 GHz or 6 GHz* bands; Supports 802.11 a/ b/ g/ n/ ac/ ax; Supports Bluetooth 5.3 |
| Graphics | |
| Graphics | 1 x HDMI, 1 x DisplayPort |
| Support Hdmi 2.1, Maximum Resolution Of 4K 60Hz | Yes |
| Supports Dp1.4, Maximum Resolution Of 4K 60Hz | Yes |
| Memory | |
| Maximum Memory | 192 GB |
| Slots | 4 DIMMs |
| Supported Memory | Memory Support DDR5 7200+(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz; Max. overclocking frequency: 1 DPC 1 R Max speed up to 7200+ MHz, 1 DPC 2 R Max speed up to 6000+ MHz, 2 DPC 1 R Max speed up to 6000+ MHz, 2 DPC 2 R Max speed up to 5400+ MHz; Supports Dual-Channel mode; Supports non-ECC, un-buffered memory; Supports AMD EXPO |
| Type | DDR5 |
| Expansion Slots | |
| Pci | 2 x PCI-E x16 slot, 1 x PCI-E x1 slot |
| Pci_E1 | Gen PCIe 4.0 supports up to x16 (From CPU) |
| Pci_E2 | Gen PCIe 3.0 supports up to x1 (From Chipset) |
| Pci_E3 | Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Others | |
| Special Features | 4 x EZ Debug LED |
| Warranty Information | |
| Warranty | 3 Years |
Description
The MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard is a powerhouse built to handle AMD Ryzen 9000, 8000 & 7000 Series Desktop Processors, providing compatibility with the most recent and powerful CPUs on the market. DDR5 memory compatibility, providing high-speed data transmission with dual-channel DDR5 7200+MHz (OC), is one of its cutting-edge characteristics. With a 12+2 Duet Rail Power System, two 8-pin CPU power connections, Core Boost, and Memory Boost, the motherboard has an upgraded power architecture that ensures reliable and efficient power supply for best performance. Its premium thermal solution includes 7W/mK MOSFET thermal pads and M.2 Shield Frozr, resulting in a high-performance system with efficient heat dissipation. The motherboard's high-quality 6-layer PCB, constructed of 2oz thicker copper, improves longevity and stability, laying the groundwork for heavy workloads. The MSI PRO B650-S WIFI Motherboard has PCIe 4.0 slots, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, and USB 3.2 Gen 2x2 connections to meet the needs of current gaming and data-intensive applications. The motherboard provides an improved network solution with 2.5G LAN and Wi-Fi 6E, giving a secure, reliable, and fast network connection suited for both professional and multimedia applications. The introduction of AUDIO BOOST offers a greater gaming experience with studio-grade sound quality, boosting total immersion for players. In conclusion, the MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard is a feature-rich option that delivers a strong, dependable foundation for gamers and professionals looking for top-tier performance and functionality.
Best MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard price in BD
MSI PRO B650-S WIFI DDR5 AM5 ATX Motherboard price in Bangladesh starts from ৳20,700. Price may vary based on configuration and availability. Order from the Primes Computers website or visit our showrooms.
