Dahua N45CL5Z 4MP Turret Varifocal Network Camera
Price: To be announced
Stock: Out of stock
Product Code: #1744
Brand: Dahua
Key Features:
High quality imaging with 4 MP resolution
Max. 4 MP (2688 × 1520) @30 fps
H.265 codec, high compression rate, ultra-low bit rate
Built-in IR LED, max. IR distance: 40 m
Intelligent detection: Intrusion, tripwire
Abnormality detection: Motion detection, video tampering, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access
Water and dust resistant (IP67)
Supports Micro SD card (up to 256 GB)
Payment Options
Selected: Cash
Specification
| General | |
| Anti-Corrosion Protection | No specific protection |
| Brand | Dahua |
| Firmware Version | V5.6.0 build 240312 |
| General Function | One-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Language | 32 languages |
| Model | N45CL5 Z |
| Startup And Operating Conditions | -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Type | 4 MP Turret Varifocal Network Camera |
| Network | |
| Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Api | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Client | iVMS-4200, Hik-Connect |
| Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Network Storage | Support for microSD/SDHC/SDXC card (256 G), local storage and NAS (NFS, SMB/CIFS), ANR |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1 X, QoS, IPv6, UDP, Bonjour |
| Security | Password protection, complicated password, HTTPS encryption, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users. 3 levels: administrator, operator and user |
| Web Browser | Plug-in required live view: IE 10, IE 11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Lens | |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 78°, Rotate: 0° to 360° |
| Aperture | F1.4 |
| Focal Length & Fov | Horizontal FOV: 104°–27°, vertical FOV: 55°–15°, diagonal FOV: 125°–31° |
| Iris Type | Auto |
| Lens Mount | M14 |
| Type | Motorized varifocal lens, 2.7 mm–13.5 mm |
| Power | |
| Approx. Power Consumption | Max. 8.5 W |
| Power Supply | 12 VDC ± 25%, 0.7 A, max. 8.5 W, Ø5.5 mm coaxial power plug; PoE: 802.3 af, Class 3 |
| Audio | |
| Audio Bit Rate | 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2) |
| Audio Compression | G.711/G.722.1/G.726/MP2L2/PCM |
| Audio Sampling Rate | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering | Yes |
| Video | |
| Bit Rate Control | CBR/VBR |
| Day/Night Switch | Day/Night/Schedule |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Main stream supports |
| H.265 Type | Main Profile |
| H.265+ | Main stream supports |
| Image Enhancement | BLC/HLC/3 D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser |
| Main Stream | 50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Region Of Interest (Roi) | 1 fixed region for main stream and sub-stream separately |
| Scalable Video Coding (Svc) | H.264 and H.265 encoding support |
| Sub-Stream | 50 Hz: 25 fps (704 × 576, 640 × 480); 60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream | 50 Hz: 25 fps (1280 × 720, 704 × 576); 60 Hz: 30 fps (1280 × 720, 704 × 480) |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Video Compression | Main stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264 |
| Image Sensor | |
| Day & Night | IR cut filter |
| Digital Noise Reduction | 3 D DNR |
| Max. Resolution | 2688 (H) × 1520 (V) |
| Min. Illumination | 0.01 Lux @ (F1.4, AGC ON), 0 Lux with IR |
| Shutter Time | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Type | 1/3-in. 4 MP Progressive-scan imager with 2.7 mm to 13.5 mm vari-focal lens |
| Wide Dynamic Range (Wdr) | 120 dB |
| Physical | |
| Dimension | Ø129.4 mm × 116.1 mm (Ø5.1" × 4.6") |
| Material | Metal + Plastic |
| Storage Conditions | -30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Weight | Approx. 760 g (1.7 lb.) |
| Compatibility | |
| Dori | 2.7 mm–13.5 mm: D: 60–180 m, O: 24–72 m, R: 12–36 m, I: 6–18 m |
| Perimeter Protection | Line crossing, intrusion (support alarm triggering by specified target types) |
| Illuminator | |
| Ir Wavelength | 850 nm |
| Smart Supplement Light | Yes |
| Supplement Light Range | Up to 40 m |
| Supplement Light Type | IR |
| Warranty Information | |
| Warranty | 1 Year |
Description
The Dahua N45CL5Z is a 4MP turret network camera with a varifocal lens, ideal for versatile surveillance in Bangladesh. Offering clear 4MP resolution and IR illumination up to 40m, it ensures reliable performance in low-light conditions. With H.265 compression and intelligent detection features, it optimizes storage and enhances security. The IP67 rating makes it suitable for indoor and outdoor use.
Perfect for commercial and residential applications, the N45CL5Z is available at affordable prices in Bangladesh for robust networking solutions.
Best Dahua N45CL5Z 4MP Turret Varifocal Network Camera price in BD
Dahua N45CL5Z 4MP Turret Varifocal Network Camera price in Bangladesh — please call/message for the latest price. Price may vary based on configuration and availability. Order from the Primes Computers website or visit our showrooms.
